Color Sensor：Hiwonder Robot Sensor Compatible with Arduino
- Voltage: DC 5V
- Current: Max 100mA
- Recognizable distance: 2~100mm
- 4 Pin wire port. Connecting wire is provided. Easy to connect
- The holes are compatible with LEGO bricks
- Product SKU: HW2019062
- Category: All Products, Arduino, Arduino2022, micro:bit&Scratch, micro:bit2, Module & Sensor, Module/Sensor, Module/Sensor, Module/Sensor, Scratch, Sensor, Sensor-1
- Order within
Available:
In Stock
$5.99
Product Description
Hiwonder color sensor is applied to the detection of object color. It is mainly adopted APDS-9960 element. Integrating RGB color detection, it can recognize various object colors. Designed with ambient light detection, it can detect light intensity under various ambient light conditions. With built-in infrared LED light, it can realize object proximity detection. In addition, fitted with four directional diodes, it can recognize gestures such as up, down, left, and right.
Features
- Voltage: DC 5V
- Current: Max 100mA
- Port type: 5264-4AW
- Size: 50mm×20mm
- Recognizable distance: 2~100mm
- Recognizable angle: Forward -20°~20°
- Date port: The fastest clock rate of I2C can reach 400kHz
Arduino Connection
Dimension Drawing
Package List
1* Hiwonder Color Sensor
1* 4PIN wire (20cm)
1* 4PIN wire (20cm)
Product Description
Hiwonder color sensor is applied to the detection of object color. It is mainly adopted APDS-9960 element. Integrating RGB color detection, it can recognize various object colors. Designed with ambient light detection, it can detect light intensity under various ambient light conditions. With built-in infrared LED light, it can realize object proximity detection. In addition, fitted with four directional diodes, it can recognize gestures such as up, down, left, and right.
Features
Arduino Connection
Dimension Drawing
Package List
1* Hiwonder Color Sensor
1* 4PIN wire (20cm)
- Voltage: DC 5V
- Current: Max 100mA
- Port type: 5264-4AW
- Size: 50mm×20mm
- Recognizable distance: 2~100mm
- Recognizable angle: Forward -20°~20°
- Date port: The fastest clock rate of I2C can reach 400kHz
Arduino Connection
Dimension Drawing
Package List
1* Hiwonder Color Sensor1* 4PIN wire (20cm)
| Item | Specification |
| Voltage | 5V |
| Current | Max 100mA |
| Port type | 5264-4AW |
| Size | 50*20mm |
| Recognizable distance | 2~100mm |
| Recognizable angle | Forward -20°~20° |
